Glass Drilling Machine ZYZ0222A

The structure of the glass drilling machine is welded by high-quality thickened 45# steel plate and annealed by high temperature. The structural performance is stable and can withstand high-intensity processing loads. The table adopts high-quality casting materials and is treated by high-temperature annealing. Stable structural performance. The machine adopts pneumatic clamping glass, the down and up drill bits are drilled successively and drilled down automatically rising, and the position and speed can be adjusted. Automatic material retrieval, table pneumatic lifting, can be mass continuous production and processing. Main Features： ◆Suitable for drilling large quantities of plate glass; ◆Glass pneumatic clamping, drilling fast feed with hydraulic buffer device, worktable pneumatic lifting; ◆Automatic feeding of down drill bit, manual feeding of upper drill bit (ZYZ0222A automatic feed can also be selected), easy to operate. There are two models of glass drilling machine ZYZ0222 series, the main differences are: ZYZ0222 type (semi-automatic type): the down drill bit is automatic, the upper drill bit is manual, and there is no infrared assisted positioning ZYZ0222A type (automatic type): down drill bit is automatic, the upper drill bit is automatic (can also be manually controlled), and there is infrared assisted positioning

Keyword

Glass drilling machine

drill hole machine

Glass hole machine

Related Products

Product Inquiry

Product Details

Mechanical introduction：
The structure of the glass drilling machine is welded by high-quality thickened 45# steel plate and annealed by high temperature. The structural performance is stable and can withstand high-intensity processing loads. The table adopts high-quality casting materials and is treated by high-temperature annealing. Stable structural performance. The Glass hole machine adopts pneumatic clamping glass, the down and up drill bits are drilled successively and drilled down automatically rising, and the position and speed can be adjusted. Automatic material retrieval, table pneumatic lifting, can be mass continuous production and processing.

Main Features：
◆Suitable for drilling large quantities of plate glass;
◆Glass pneumatic clamping, drilling fast feed with hydraulic buffer device, worktable pneumatic lifting;
◆Automatic feeding of down drill bit, manual feeding of upper drill bit (ZYZ0222A automatic feed can also be selected), easy to operate.

There are two models of glass drilling hole machine ZYZ0222 series, the main differences are:
ZYZ0222 type (semi-automatic type): the down drill bit is automatic, the upper drill bit is manual, and there is no infrared assisted positioning
ZYZ0222A type (automatic type): down drill bit is automatic, the upper drill bit is automatic (can also be manually controlled), and there is infrared assisted positioning
