Laminated Glass Cutting Machine ZLM3826

The company's research and development and production of laminated glass cutting machine ZLM2620/ ZLM3826/ZLM6033 high-precision double-knife semi-automatic laminated glass cutting machine is widely used in the offline cutting of thick flat glass and laminated glass. The equipment is convenient to operate, reliable and stable operation, cutting efficiency and high precision. It adopts PLC control, touch screen operation, Chinese and English interface, stepper motor drive (servo motor configuration can be selected), synchronous belt transmission system. The operation is more convenient and the performance is stable. The cutting speed can be set directly. The up and down cutter heads are cut in pairs, the degree of consistency is high, and the pieces are easy to break. Main features: ◆Optimize typography ◆Fully automatic breaking ◆Production database ◆High speed quartz tube heating ◆Belt conveyor ◆Mechanical and Photoelectric Positioning ◆Chinese and English interface; Main parameters： 1、Max cutting size：ZLM2620:2600*1900mm / ZLM3826:3800*2500mm / ZLM6033:6000*3200mm 2、Min glass cutting length：200mm 3、Cutting speed：100m/min 4、Positioning accuracy：±0.25mm 5、Linear cutting accuracy：±0.3mm 6、Parallel precision：±0.2mm 7、Diagonal accuracy：±0.5mm 8、Thickness of single glass：3-10mm 9、Glass lamination thickness：0.38-1.52mm 10、Workbench height :900±50mm 11、Total power：15Kw 12、Minimum air pressure：0.8Mpa

Keyword

Laminated Glass Cutting Machine

Laminated Cutting Machine

laminated glass cutting

Related Products

Product Inquiry

Product Details

Mechanical introduction：
The company's research and development and production of laminated glass cutting machine ZLM2620/ ZLM3826/ZLM6033 high-precision double-knife semi-automatic laminated glass cutting table is widely used in the offline cutting of thick flat glass and laminated glass. The equipment is convenient to operate, reliable and stable operation, cutting efficiency and high precision. It adopts PLC control, touch screen operation, Chinese and English interface, stepper motor drive (servo motor configuration can be selected), synchronous belt transmission system. The operation is more convenient and the performance is stable. The cutting speed can be set directly. The up and down cutter heads are cut in pairs, the degree of consistency is high, and the pieces are easy to break.

Main features:
◆Optimize typography
◆Fully automatic breaking
◆Production database
◆High speed quartz tube heating
◆Belt conveyor
◆Mechanical and Photoelectric Positioning
◆Chinese and English interface;

Main parameters：
1、Max cutting size：ZLM2620:2600*1900mm / ZLM3826:3800*2500mm / ZLM6033:6000*3200mm
2、Min glass cutting length：200mm
3、Cutting speed：100m/min
4、Positioning accuracy：±0.25mm
5、Linear cutting accuracy：±0.3mm
6、Parallel precision：±0.2mm
7、Diagonal accuracy：±0.5mm
8、Thickness of single glass：3-10mm
9、Glass lamination thickness：0.38-1.52mm
10、Workbench height :900±50mm
11、Total power：15Kw
12、Minimum air pressure：0.8Mpa
